Power @ 1-Ohm: 1 x 500W - 5th Channel Only Power @ 2-Ohms: 4 x 160W + 1 x 600W Power @ 4-Ohms: 4 x 80W + 1 x 300W Fuses: 2 x 50A Maxi Dimensions: 15.98 X 8.86 X 2.36 in
Super A/B Class + Super D-Class Variable Voltage 0.2V~6.0V Signal to Noise Ratio >93dB Frequency Response 10Hz-45kHz Crossover Type Electronic 12dB Per Octave Crossover Frequency Range CH1 & CH2 High Pass 50Hz - 4kHz Crossover Frequency Range CH3 & CH4 Hi Pass 250Hz - 4Khz Low Pass 40Hz-250Hz Crossover Frequency Range CH 5 (TMA-800-5 only) Low Pass 30Hz - 150Hz Tone Control Bass EQ 0~10dB@45Hz
