champion Series
Maximum Peak Power Handling: 1600 Watts
Continuous Power Handling (rms): 500 Watts
Sensitivity (1w/1m) 92 Db
Frequency Range: 20 Hz To 1.6 Khz
Dual 4 Ohm Voice Coils
12? Honeycomb Impp™ Composite Cone Structure
Dual Layer Fiber Reinforced Elastic Polymer Surround
90 Oz Ferrite Magnet
Basket Material: Reinforced Stamped Steel
Mounting Depth: 6.125?
cut Out Dimensions: 11.125?
Equivalent Compliance (vas): 37.7
Free Air Resonance (fs): 38
Linear Excursion (xmax): 11.3
Port Diameter: 3?
Port Length: 6.5?
Recommended Ported Box Volume: 1.5 Cu Ft / 42.5 Liters
Recommended Sealed Enclosure Volume: 1.25 Cu Ft / 35.4 Liters
Total Speaker “q” (qts): 0.73
