PPE Premium High-Efficiency Oil Filter (Tall) 114000750 (Replaces AC Delco PF26)

Pacific Performance Premium High-Efficiency Engine Oil Filter for ’20-Current GM 6.6L Duramax 522 square inches of specially engineered 5-micron media Thicker threaded plate with 49% larger oil passages Silicone anti-drain-back valve Perforated metal center tube provides core strength for filter media Bypass valve (OEM required) has a stiffer spring and a rubber seal Coil spring eliminates oil blow-by Integrated internal magnet with retainer Compatible with synthetic and conventional oils 2020+ GM 6.6L Duramax High-Efficiency Engine Oil Filter (replaces AC Delco PF26) This oversized PPE Engine Oil Filter has 2 times the specially engineered filter media equaling 522 square inches, which is over 100% larger media than OEM. A perforated metal center core and spiral-wrapped adhesive provides media support, preventing collapse. This filter also includes a high-power magnet to catch ferrous metal debris, preventing it from circulating or clogging the filter paper. The silicone anti-drain-back valve prevents engine dry starts. The bypass valve features a stiffer spring and a rubber seal. The base plate is also made thicker to accommodate increased oil pressures in high-performance applications. The OEM PF26 filter comes up short with only 259 square inches of 30-micron filtration capability. The stock leaf spring loses tension and can lead to dirty oil blow-by. The OEM filter bypass valve comes with no seal of any kind. Note: This oversize filter requires the use of the PPE Fuel Pump Relocation Bracket (2020-2024 L5P); P/N 114002700.
